Rigel – X1
Technical Specifications
| Operating input voltage range | : | 100-300 Vac; 50/60 Hz; 140-300 Vdc |
| Over voltage protection | : | Yes. 320 Vac ( +/- 10 V ) |
| Under voltage protection | : | Yes. 110 Vac ( +/- 10 V ) |
| Thermal protection | : | Yes. 110°c +/- 10°c |
| THD | : | <10% |
| Efficiency | : | >85% |
| PF | : | > 0.98 |
| Standard loss | : | 0.3 Watt |
| Withstand Voltage | : | 440 Vac |
| Working temperature (ta) | : | -20°c to + 65°c |
| Case temperature (tc) | : | +85°c |
| SAFETY standards | : | IS 15885 (PART2/SEC13), IEC 61347-2-13: Ed1206-5 IEC 60950, IS 16104 |
| Connections | : | Wire for Input & Output |
| Dimension (L*W*H)(MM) | : | 123*36*27 |
Dimensional Details
Features
- Protection : Output Short Circuit, Over Voltage, Under Voltage, No load
- Built-in active PFC function
- IP 20/65 design Universal AC input (up to 300 Vac)/full range
- Meet 4 KV Surge Immunity Level (IEC61000-4-5)
- Class I power units I pass LPS
- Suitable for dry, damp & wet location
- Suitable for Indoor/Outdoor LED Lighting
- 3/5 Years Warranty
Electrical Specifications
RIGEL - X1 ( Input 15 - 40 watt )
| Serial Number | Output Voltage Min- Max | Output Current Min- Max | Output Wattage Min- Max |
| 01 | 25-40 v | 350-1000 mA | 13W – 36W |
| 02 | 40-60 v | 300-550 mA | 13W – 36W |
| 03 | 50-70 v | 300-500 mA | 13W – 36W |
| 04 | 60-80 v | 400-550 mA | 13W – 36W |
